TS-01 Digital Temperature Sensor

Name: TS-01 Digital Temperature Sensor

On Line Service :
Print this page	Bookmark this
Inquiry product	E-mail Us
Live Messenger	Skype Online
PDF Download

Tages:TS-01 Digital Temperature Sensor

TS-01

Digital Temperature Sensor

Exclusive accessory for GCU-2000 Digital Genset PLC Control Unit

TS-01 Digital Temperature Sensor the most accurate temperature sensor available with accuracy -25 °C to 100 °C ±2.0 °C (max.) with exceptional vibration tolerance.

Features

Accuracy -25~100 °C ±2.0 °C (Max.)
Operating Temperature Range -55~125 °C
Display Accuracy 0.5 °C / step
ESD Protection 2000V
Transmission Distance 30M
Waterproof Integral Electrical Connector
Exceptional Shake and Vibration Tolerance
No Adjustment Needed, 100% Compatibility if New Sensor Replaced
Built in Digital Sensor, Excellent Accuracy, More Precise Than the Traditional Thermocouple or Resistance Temperature Sensor
Extremely Stable Linearity Output, No need for Adjustment After Installation or Maintenance

Specifications

Model NO.	TS-01
Supply Voltage	3.0~5.5 VDC
Supply Current	1.0 mA
Accuracy	-25~100 °C ±2.0 °C (Max.)
Display Accuracy	0.5 °C / Step
Burst Temperature	260 °C (10 sec.)
ESD Protection	2000V
Output Interface	SMBus Interface
Thread	M16-1.5
Ingress Protection	IP65
Operating Temperature	-55~125 °C
Dimensions	TS-01-2.5 : 2.5M TS-01-5.0 : 5.0M
Weight	TS-01-2.5 : 154 g ±2% TS-01-5.0 : 249 g ±2%

*Note : All features amp; specifications subject to change without notice.
