AMF-10R Relay Module for AMF-10

Name: AMF-10R Relay Module for AMF-10

On Line Service :
Print this page	Bookmark this
Inquiry product	E-mail Us
Live Messenger	Skype Online
PDF Download

Tages:AMF-10R Relay Module for AMF-10

AMF-10R

Relay Module for AMF-10

The AMF-10R universal AMF Controller Interface Module is use to simplify wiring in electrical operation and mechanical maintenance transfer switch connecting to assorted brand AMF Controller available on the worldwide Markets. It allows wide range of operating power inputs from 9~35 VDC and by alter the wiring connection the system voltage changes from AC220V to AC380V without the use of transformer.

Features

For use in Electrical Operation and Mechanical Maintenance Transfer Switch connecting to Assorted Brand AMF Controller Available on the Market
Simplify All Wiring with Pluggable Terminal Block
Easy Assembly amp; Maintenance with No Chance of Wiring Mistakes
Circuits are Finger Safe with UL94-V0 Epoxy Protection
Built-In 3 Phase Fuses to Protect Mains amp; Generator Circuits
Build-In Adjustable Transfer Delay Time for Mains and Generator (10~15 Seconds)

Specifications

Item	Function	Current	Fuse Capacity
F1	Protect Normal Power Circuit	6.3A	50 KA @ 500 VAC
F2	Protect Normal Power Circuit	6.3A	50 KA @ 500 VAC
F3	Protect Normal Power Circuit	6.3A	50 KA @ 500 VAC
F4	Protect Emergency Power Circuit	6.3A	50 KA @ 500 VAC
F5	Protect Emergency Power Circuit	6.3A	50 KA @ 500 VAC
F6	Protect Emergency Power Circuit	6.3A	50 KA @ 500 VAC
Item	Function	Capacity
TB1	Connect to Transfer Switch	300 VAC / 15A
TB2	Connect to AMF Controller	300 VAC / 15A
Mains " ON "	Transfer from Generator to Mains	250 VAC / 7A
Generator " ON "	Transfer from Mains to Generator	250 VAC / 7A
Dimensions amp; Weight
Dimensions	150.0 (L) x 135.0 (W) x 45.5 (H) mm
Weight	260 g ±2%

*Note : All features amp; specifications subject to change without notice.
