PERFORMANCE :

RPM Stability:

lt;±0.25%

Speed Range:

1KHz ~ 7.5KHz

Speed Drift with Temperature:

Max ±1%

IDLE adjustment:

160 ± 20Hz ~ 95% of set speed

DROOP Regulation:

Minimum 15Hz ±6Hz/ 1 Amp change

Maximum: 400Hz ±75Hz/ 1 Amp change

Speed Trim Range:

± 200Hz (external 1KΩ)

AUX Input Sensitivity:

148Hz / 1V., ± 10Hz, Impedance 1MΩ

START FUEL Regulation:

160 ± 20Hz ~ 70% of set speed

RAMP Regulation Time:

1.5 ~ 20Sec.

Output Current at 10V:

20mA Max.

ENVIRONMENT:

Operating temperature range:

-40 °c ~ 85 °c

Working Humidity Range:

Maximum 95%

Stocking Temp:

-55 ~ 90 °C

Shocking:

20-100HZ 500mm/Sec.

INPUT POWER SUPPLY:

Voltage:

12V or 24V DC Battery Systems

Grounding Pole:

Negative pole

Power Consumption:

50mA

Actuator Current Range(25°c)-(Inductive Load):

Min. 2.5A; Max. 10A continuous

MPU:

Signal:

0.5 ~ 120 RMS
