KUTAI EA16 AVR for Marelli M40FA640A-MARK I and Caterpillar

Name: KUTAI EA16 AVR for Marelli M40FA640A-MARK I and Caterpillar

On Line Service :
Print this page	Bookmark this
Inquiry product	E-mail Us
Live Messenger	Skype Online
PDF Download

Tages:AVR Compatible with Marelli M40FA640A-MARK I and Caterpillar

EA16
AVR Compatible with Marelli M40FA640A-MARK I and Caterpillar
EA16 16Amp half wave automatic voltage regulator can be used in genset parallel operation. It's compatible with Marelli, Caterpillar, Khenkikian, and Genaust avrs.

EA16-400Hz AVR 16 Amp half wave suitable for genset paralleling

EA16-400Hz 16Amp half wave automatic voltage regulator with 400 Hz sensing input. The AVR can be used in genset parallel operation and a popular universal replacement for generator with 400 Hz output.

Features

Voltage Regulation lt; ±0.5%
Suitable for brushless type generator Sensing Input 170~510 VAC
Can be used in Parallel Operation
16 ADC Current Output
EA16 Suitable Frequency 50/60 Hz , EA16-400Hz Suitable Frequency 400 Hz
Soft Start Voltage Ramping
Load CT Current Compensation, Analogue Voltage Input

Specifications

If you have any enquiry about quotation or cooperation, please feel free to email us at parts@powergensetparts.com or use the following enquiry form. Our sales representative will contact you within 24 hours. Thank you for your interest in our products.

[Prev] [Back] [Next]

Title:	*
Contact person:	*
Telephone:	*
Fax:
E-mail:	*
Address:
Messages:	*
Know us from:

Model NO.	EA16	EA16-400Hz
Sensing Input	Voltage 170~510 VAC single phase 2 wire	Voltage 170~510 VAC single phase 2 wire
Sensing Input	Frequency 50/60 Hz	Frequency 400 Hz
Power Input	Voltage 60~300 VAC single phase 2 wire	Voltage 60~300 VAC single phase 2 wire Max. 90 VDC @ 240 VAC input
Output	Voltage Max. 90 VDC @ 240 VAC input Current Continuous 16A, Max. Intermittent 20A for 10 sec. Resistance Min. 6 Ohm @ 35 VDC	Voltage Max. 90 VDC @ 240 VAC input Current Continuous 16A, Max. Intermittent 20A for 10 sec. Resistance Min. 6 Ohm @ 35 VDC
Voltage Regulation	lt; ±0.5% (with 4% engine governing)	lt; ±0.5% (with 4% engine governing)
Voltage Build-up	Residual volts at AVR terminal gt; 5 VAC	Residual volts at AVR terminal gt; 5 VAC
External Volts Adjustment	±5% with 2 K Ohm 1 watt trimmer	±5% with 2 K Ohm 1 watt trimmer
Unit Power Dissipation	Max. 10 watt	Max. 10 watt
Thermal Drift	0.03% per °C change in AVR ambient	0.03% per °C change in AVR ambient
Under Frequency Protection	55 Hz @ 60 Hz / 45 Hz @ 55 Hz (Adjustable)	320 Hz (Adjustable)
CT Current Compensation Input	1A or 5A (Selectable)	1A or 5A (Selectable)
Analogue Input	±5 VDC ±10% AC @ ±3 VDC	±5 VDC ±10% AC @ ±3 VDC
Environment	Operating Temperature : -40~70 °C Storage Temperature : -40~85 °C Relative Humidity : Maximum 95% Vibration : 3.3G @ 100~2 KHz	Operating Temperature : -40~70 °C Storage Temperature : -40~85 °C Relative Humidity : Maximum 95% Vibration : 3.3G @ 100~2 KHz
AVR Controls Functions	VOLT : Voltage Adjustment STAB : Stability Adjustment U/F^: To Set the U/F Knee Point DROOP : To Adjust Droop TRIM : Analogue Input Adjustment (U/F: Under Frequency Protection)	VOLT : Voltage Adjustment STAB : Stability Adjustment U/F^: To Set the U/F Knee Point DROOP : To Adjust Droop TRIM : Analogue Input Adjustment (U/F: Under Frequency Protection)
Dimensions	156.0 (L) x 106.0 (W) x 43.0 (H) mm	156.0 (L) x 106.0 (W) x 43.0 (H) mm
Weight	450 g ±2%	450 g ±2%
