GCU-10 Generator Control Unit

Name: GCU-10 Generator Control Unit

On Line Service :
Print this page	Bookmark this
Inquiry product	E-mail Us
Live Messenger	Skype Online
PDF Download

Tages:GCU-10 Generator Control Unit

GCU-10

Generator Control Unit

The GCU-10 Generator Control Unit is an universal economical programmable genset controller. Equipped with high illuminating LED with universal graphical interface helps to notify the operator the generator status. Optional relay module GCU-11R (12V/24V) helps to simplify the wiring and connection process.

Features

Microprocessor Based Design
Universal LED Graphic Interface, Displays Generator Status and Failures
Modular Design, Quick Installation
Programmable Engine amp; Generator Controls Adapts Easily To Any Type Generator Set.
Waterproof Front Panel With UV Protection
Provide IDLE control For Elec. Governors
Five Adjustable Time Delay Potentiometers
Five DIP Switches For Specification Setting

Specifications

Model NO.	GCU-10
DC Supply	9.0 to 36 VDC
Alternator Input Range	Voltage 5~300 VDC Frequency 50~60 Hz
Fuel Solenoid Signal Output	5 Amp @ 12/24 VDC
Start Signal Output	5 Amp @ 12/24 VDC
Warm up Signal Output	5 Amp @ 12/24 VDC
Accessory " ON " Output	5 Amp @ 12/24 VDC
Idle Control Conductor Capacity	5 Amp @ 12/24 VDC
Power Consumption	Under 3 VA on Auto
Protection amp; Alarm Status Indicators	Start Failure High Water Temperature Low Oil Pressure Overspeed Underspeed Emergency Stop Extra Prog. Input Low Battery Voltage
Adjustable Timers	Engine Pre-Heat : 2~30 sec. Starter Cranking Time : 1~15 sec. Energize to STOP : 1~30 sec. Engine Idle (Governor) : 0~300 sec. Engine Cool-down : 0~300 sec.
Environment	Operation Temperature : -20~70 °C Relative Humidity : Maximum 90%
Panel Installation Cut-Out	66.0 x 66.0 ±0.5 mm
Dimensions	72.0 (L) x 72.0 (W) x 50.0 (H) mm
Weight	166 g ±2%
