AMF-10 Control Protection Module

Name: AMF-10 Control Protection Module

On Line Service :
Print this page	Bookmark this
Inquiry product	E-mail Us
Live Messenger	Skype Online
PDF Download

Tages:AMF-10 Control amp; Protection Module

AMF-10

Automatic Mains Failure Control amp; Protection Module

The AMF-10 is an universal Automatic Mains Failure Control amp; Protection Module. It is a control and protection module for the generator and a monitoring controller for the Automatic Transfer Switch. The modularity design with easy to read high illuminant LED display, universal warning symbols and easy to operate interface, all functions settings can be programmed directly from the front panel. Optional AMF-10R universal AMF Controller Interface Module (relay module) is available for the AMF-10 to simplify the wiring and connection process.

Features

Micro-Processor Auto Control amp; Protection
Easy to Read High Light LED Display
Modularity Design, Easy to Install
Compact Size with Vibration Protected
Waterproof Front Panel With IP65
Provide Full Mains and Genset Alarms Signals shutdowns
All Functions Setting Can be Done Directly On AMF-10 No Need For PC Connection*
Universal LED Graphic Interface, Displays ATS and Genset Status and Failures

*Customized settings are auto-saved into memory and will remain even when power is off.

Specifications

Model NO.	AMF-10
Power Input	Voltage 9~36 VDC (12V , 24V)
Sensing Input	Voltage 15~510 VAC Frequency 50/60 Hz
Rated Output Capacity	DC 10 Amps @ 12/24 VDC AC 8 Amps @ 250 VAC
CT Specifications	Burden Above 2.5 VA
CT Secondary RatedAmps	5A
Power Dissipating	Max. 5 watt
Protection amp; Alarm Status	Engine Start Failure High Coolant Temperature. Engine Over Speed Abnormal AC Voltage Low Fuel Level Maintain Service Alarm Emergency Stop Low Oil Pressure Engine Under Speed Generator Over Load Abnormal Battery Voltage Programmable Alarm
4 Digit 7 Segment Easy-to-Read LED Display	Programmable Display with 3 Phase Volts,Amp amp; Freq. Engine Operation Hours amp; Battery Voltage Display Internal Program Settings amp; Status Failure Signal Status By Graphic Display
Environment	Operation Temperature : -20~70 °C Relative Humidity : Maximum 95% Max. Vibration : 5~25 Hz , ±1.6 mm 25~100 Hz , a=4g
Panel Installation Cut-Out	137.0 x 137.0 ±0.5 mm
Dimensions	147.8 (L) x 147.8 (W) x 62.3 (H) mm
Weight	589 g ±2%

*Note : All features amp; specifications subject to change without notice.
