GCU-20 Automatic Engine Generator Control Unit

Name: GCU-20 Automatic Engine Generator Control Unit

On Line Service :
Print this page	Bookmark this
Inquiry product	E-mail Us
Live Messenger	Skype Online
PDF Download

Tages:GCU-20 Automatic Engine Generator Control Unit

GCU-20

Automatic Engine amp; Generator Control Unit

GCU-20 Automatic Engine amp; Generator Control Unit has many useful functions like annunciator alarm output and selectable EM81 / EM121 MPU signal for speed sensing. It's suitable for pump engine control. GCU-20 also provide IDLE control for electronic governors.

Features

Microprocessor Based Design
Universal LED Graphic Interface, Displays Generator Status and Failures
Modular Design, Quick Installation
With Annunciator Alarm Output
Selectable MPU Signal for Speed Sensing
Suitable for Pump Engine control
With Lamp Test Function for All Front Panel LEDs and Annunciator Lamps
Provide IDLE control For Elec. Governors
Five Adjustable Time Delay Potentiometers
Six DIP Switches For Setting Different Engine Parameters

Specifications

Model NO.	GCU-20
DC Supply	9.0 to 36 VDC
Alternator Input Range	5~300 VAC 50/60 Hz
MPU Signal Input Range	±2V to 70V Peak
Rated MPU Frequency	100 Hz ~ 10,000 Hz
Fuel Solenoid Signal Output	10 Amp @ 12/24 VDC
Start Signal Output	10 Amp @ 12/24 VDC
Annunciator Output	300 mA @ 12/24 VDC
Power Consumption	Under 3 watt
Protection amp; Alarm Status Indicators	Start Failure High Water Temp. Low Oil Pressure No Speed Signal Overspeed Underspeed Extra Prog. Input
Adjustable Timers	Engine Pre-Heat : 2~30 Seconds Starter Cranking Time : 1~15 Seconds Energize to STOP : 1~15 Seconds Engine Idle (Governor) : 0~300 Seconds ngine Cool-Down : 0~300 Seconds
Environment	Operating Temperature : -20~70 °C Storage Temperature :-35~85 °C Relative Humidity : Maximum 90%
Dimensions	88.0 (L) x 88.0 (W) x 37.5 (H) mm
Weight	206 g ±2%

*Note : All features amp; specifications subject to change without notice.
