ADVANCED FEATURES

Multi-Stage Intelligent Charging
• Constant current- Maximum current available during charge recovery phase
• Constant voltage
• Chargers automatically return to float mode when charging is complete

Low Output Ripple
• Makes the chargers ideal for all battery types

Full Protection
• Reverse polarity protection, short circuit protection and current limiting
• Automatic recovery after the removal of fault conditions

Boost Mode
• Boosts and equalises cell charge improving battery performance and life
• Simple boost connection using on-board terminals

Power Save Mode
• Once the battery is fully charged the chargers switch to Eco-
Power to save energy

KEY BENEFITS

• Suitable for a wide range of battery types
• No moving parts for longer battery charger life
• Switched mode design
• Charger fail output
• Minimum 80% efficiency throughout full operating range

AC SUPPLY

VOLTAGE RANGE
90 V to 305 V (L-N)

FREQUENCY RANGE
48 Hz to 64 Hz (L-N)

DC OUTPUT

OUTPUT
10 A DC 24 V DC at 27.6 V DC

RIPPLE AND NOISE
lt;1%

EFFICIENCY
gt;80%

REGULATION

LINE
lt;1% Vo

LOAD
lt;2% Vo

PROTECTIONS
Short Circuit
Over Current
Reverse Polarity

DIMENSIONS

OVERALL
152 mm x 188 mm x 62 mm
6” x 7.4”x 2.44”

WEIGHT
0.8 kg
